B & C :: B & C Co-Axial Speakers :: B & C 12 inch Coaxial :: B & C 12FCX76
B & C

B&C 12FCX76 12" 350W 8 Ohm

Product Code: BAC12FCX76A Brand: B & C Model: 12FCX76
B&C 12FCX76 12 inch 350W 8 Ohm
£223.76
£223.76 ex VAT
Decrease Increase
Usually available in <br>4-6 weeks
Usually available in
4-6 weeks
Sorry we dont have a delivery price for Country
Export prices without Sales Tax or VAT - additional customs fees may apply in your country
B&C 12FCX76 12" 350W 8 Ohm

  • 700 W continuous program power capacity
  • 80° nominal coverage
  • 47 - 18000 Hz response
  • 98 dB sensitivity
  • 50.5 mm (2”) HF unit exit diameter
Specifications:

  • Nominal diameter 320 mm
  • Nominal impedance 8 ohms
  • Minimum impedance lf 6.3 ohms
  • Minimum impedance hf 7.8 ohms
  • Frequency range 47 - 18000 Hz
  • Dispersion angle 80 degrees (conical)
  • Magnet material Ceramic


Specifications LF Unit:

  • LF Sensitivity 98.0 dB
  • LF Nominal Power Handling 350 W
  • LF Continuous Power Handling 700 W
  • LF Voice Coil Diameter 76 mm
  • LF Winding Material Copper


Specifications HF Unit:

  • HF Sensitivity 106.0 dB
  • HF Nominal Power Handling 80 W
  • HF Continuous Power Handling 160 W
  • HF Voice Coil Diameter 75 mm
  • HF Winding Material Aluminium
  • Diaphragm material Titanium
  • Recommended crossover 1.2 kHz


Parameters:

  • Fs: 47 Hz
  • Re 5.3 ohms
  • Qes 0.35
  • Qms 11.0
  • Qts 0.34
  • Vas 82.0 dm3
  • Sd 522.0 cm2
  • Reference efficiency 2.3 %
  • Xmax 6.5 mm
  • Xvar 5.0 mm
  • Mms 54 g
  • Bl 15.6 Txm
  • Le 1.3 mH
  • EBP 134 Hz


  • Mounting And Shipping Info:

    • Overall diameter 315 mm
    • Bolt circle diameter 298 mm
    • Baffle cutout diameter 282 mm
    • Depth 169 mm
    • Flange and gasket thickness 14 mm
    • Net weight 8.0 kg
    • Shipping weight 8.7 kg
    • Shipping box 446x439x253 mm
    • Recone kit lf RCK12FCX768
    • Replacement diaphragm hf MMD3BTN8M
