Specifications

• Nominal diameter 127 mm (5.0 in)
• Nominal impedance 8 ohms
• Minimum impedance 6.3 ohms
• Nominal power handling 110 W
• Continuous power handling 220 W
• Sensitivity (1W/1m) 99.0 dB
• Frequency range 300-3500 Hz
• Voice coil diameter 38 mm (1.5 in)
• Winding material Aluminium
• Former material Glass Fibre
• Winding depth 7.0 mm (0.29 in)
• Magnetic gap depth 6.0 mm (0.24 in)
• Flux density 1.45 T

Design

• Surround shape Double Roll
• Cone shape Radial
• Magnet material Neodymium Ring
• Spider Single
• Pole design T-Pole
• Woofer cone treatment WP Waterproof Front Side

Parameters

• Fs 300 Hz
• Re 5.3 Ω
• Qes 0.99
• Qms 4.1
• Qts 0.79
• Vas 0.3 dm3 (0.01 ft3)
• Sd 95.0 cm2 (14.73 in2)
• η₀ 1.15 %
• Xmax 2.2 mm
• Xvar 3.0 mm
• Mms 9 g
• Bl 10.1 Txm
• Le 0.15 mH
• EBP 303 Hz

Mounting And Shipping Info

• Overall diameter 157 mm (6.18 in)
• Bolt circle diameter 142 mm (5.59 in)
• Baffle cutout diameter 122 mm (4.8 in)
• Depth 108 mm (4.25 in)
• Flange and gasket thickness 9 mm (0.35 in)
• Air volume occupied by driver 1.2 dm3 (0.04 ft3)
• Net weight 1.37 kg (3 lb)
• Shipping units 1
• Shipping weight 1.82 kg (4.0 lb)
• Shipping box 255x255x150 mm (10x10x6 in)
