TECHNICAL SPECIFICATIONS:
- Nominal diameter 300 mm 12 in
- Nominal impedance 8 Ohm
- Minimum impedance 7 ohm
- Power capacity 700 W AES
- Program power 1400 W
- Sensitivity 99 dB 1 W/1 m @ ZN
- Frequency range 60-4000 Hz
- Recommended enclosure volume 40 l
- Voice coil diameter 76.2 mm 3 in
- BL factor 23.6 N/A
- Moving mass 0.077 kg
- Winding length 18 mm
- Air gap height 10 mm
- Xdamage pp 48 mm
Thiele and Small parameters: Need some help? Read our quick guide to TS Params.
-
Fs 58 Hz
- Re 5.2 ohm
- Qms 3.6
- Qes 0.26
- Qts 0.24
- Vas 42 l
- Cms 97 µm / N
- Rms 7.7 kg/s
- Efficiency % 3
- Sd 0.055 m²
- Xmax 7 mm
- Vd 375 cm³
- Le @1 kHz 0.9 mH
CONSTRUCTIVE DETAILS:-
Depth 145 mm 5.7 in
- Net weight 3.7 kg 8.14lb
- Total weight 4.4 kg 9.7 lb
- Magnet Neodymium
