Beyma 15QLEX1600FE 15" 1600W 8 Ohm Speaker
- High power handling and low distortion 15\' subwoofer
- High force factor design for top performance applications
- Exclusive Malt Cross Technology Cooling System
- Low power compression losses
- High sensitivity: 96 dB (1W / 1m)
- FEA optimized ceramic magnetic circuit
- Aluminium demodulating ring
- Ultra low air noise
- Optimised linear behaviour
- Exclusive NCR membrane (Neck Coupling Reinforcement)
- Waterproof cone with treatment for both sides
- Double silicone spider
- 4" QUATTRO in/out copper voice coil
- Extended controlled displacement: Xmax ± 13 mm
- 60 mm peak-to-peak excursion before damage
- Optimised for direct radiation and band-pass subwoofer applications
Technical Specifications:
Thiele Small Parameters:
Construction Details:
- Nominal impedance 8 Ohm
- Power capacity 1600 W AES
- Nominal diameter 380 mm 15 in
- Sensitivity 96 dB 1 W/1 m @ ZN
- Minimum impedance 6.3 ohm
- Frequency range 35-1000 Hz
- Program power 3200 W
- Recommended enclosure volume 80 l
- Voice coil diameter 101.6 mm 4 in
- BL factor 35.6 N/A
- Moving mass 0.254 kg
- Winding length 32 mm
- Air gap height 15 mm
- Xdamage pp 60 mm
Thiele Small Parameters:
- Fs 33 Hz
- Re 5.3 ohm
- Qms 6.3
- Qes 0.22
- Qts 0.21
- Vas 102 l
- Cms 93 µm / N
- Rms 8.3 kg/s
- Efficiency % 1.6
- Sd 0.088 m²
- Xmax 13 mm
- Vd 1144 cm³
- Le @1 kHz 3.7 mH
Construction Details:
- Depth 191 mm 7.5 in
- Net weight 13.9 kg 30.6 lb
- Total weight 14.9 kg 32.8 lb
- Magnet Ferrite
