dB-Mark XCA24 PLUS V2 - 2-in 4-out Digital Active Crossover
2 input 4 output Pro Speaker Management System Controller

Product Code: DBMXCA24PLUS | Brand: dBMark
dB-Mark XCA24 PLUS V2 - 2-in 4-out Digital Active Crossover
£329.00
£274.17 ex VAT
Login to see JAM Club pricing
Not a member? Join Now
£2.10 DELIVERY to mainland UK.
dB-Mark XCA24 PLUS V2 - 2-in 4-out Digital Active Crossover

The db-Mark XCA24 digital active crossover is a high-performance audio device that offers superior audio quality with low THD and high SNR. With 2 balanced inputs and 4 balanced outputs, it features fully adjustable crossover filters with a choice of slope and curve options, as well as dynamic EQ, noise gate, and adjustable compressor on each input. The device also offers automatic gain control, configurable compressor and peak limiter, delay control, full matrix mixing, and the ability to mute individual channels. With a 32-bit digital signal processor and 24-bit 96KHz A/D and D/A converters, it provides convenient control via front panel, Windows app, or web interface, and can store up to 30 user presets. The device also has LED indicators and a blue back-lit LCD display, weighs 5.25kg, and has dimensions of 562mm x 325mm x 98mm. It operates on 110V/220V AC 50/60Hz with a power consumption of <25W.

Please click here to visit www.dbmark.co.uk downloads page for all relevant software

All XCA PLUS V2 models since July 2021 have ethernet connectivity with web based GUI, allowing you to control the settings from any Windows based device on the same network that supports a modern browser with javascript enabled.


  • 2 balanced inputs and 4 balanced outputs on XLRs.
  • XCA Series offers superior audio quality with THD: <0.002% and SNR >108.8dB
  • All channels can be configured using Parametric EQ, High/Low Shelf EQ, and 1st/2nd order All Pass filters.
  • Fully adjustable crossover filters on all output channels, with slopes from 12dB to 48dB per octave.
  • Linkwitz-Riley, Butterworth, or Bessel curves can be individually selected on the high-pass and low-pass.
  • Each input has 2 dynamic EQs, noise gate, and adjustable compressor.
  • Automatic Gain Control available on input channels.
  • Configurable compressor and peak limiter on every output channel.
  • Delay on all channels, adjustable in milliseconds, metres or feet.
  • Full matrix mixing, route any input to any output.
  • All input and output channels can be individually muted.
  • Channels can be linked for convenience to allow editing of two or more channels at a time
  • 32-bit digital signal processor with 24-bit 96KHz A/D and D/A converters.
  • USB 2.0/3.0, RS485 connections are provided for PC control of multiple devices.
  • Operation possible using the front panel controls, dedicated Windows app or the built-in web interface
  • 30 user-program presets can be stored into the device and recalled, or backed-up to PC via USB.
  • Password protection for partial or full lock of system settings.
  • LED indicators on all input and output channels for level, mute, compressor, limiter, and peak/clip.
  • 2x24 character dot-matrix blue back-lit LCD display.
  • Gross weight: 5.25kg
  • Shipping Dimensions: 562mm x 325mm x 98mm
  • Power 110V /220V AC 50/60Hz <25W
  • DAC Chip: PCM1798 often used in audiophile grade CD Players due to excellent dynamic range and low THD N
  • ADC Chip: PCM4202 offers greatly improved THD N compared with older XCA Series (AK5388)
  • DSP Chip: TMS320C6722 capable of up to 1500 MFLOPS
  • Op Amps: Texas Instruments OPA1678 and OPA1679 offering ultra low THD for hi-fi applications
