Lavoce MAN062.00-16 - 6.5" 250W 16 Ohm Loudspeaker
Key features
- 2 INCH CCAW VOICE COIL
- 97,5 dB/SPL SENSITIVITY
- 500 WATT PROGRAM POWER HANDLING
- FEM OPTIMIZED MOTOR AND SUSPENSIONS
- OPTIMIZED COOLING SYSTEM
Technical specifications
- Nominal Diameter: 165 mm (6.5in)
- Impedance: 16 Ohm
- AES Power: 250 W
- Program Power: 500 W
- Sensitivity: 97.5 dB
- Frequency Range: 100 - 4000 Hz
- Voice Coil Material: CCAW
- Voice Coil Former: Glass Fiber
- Voice Coil Depth: 10.8 mm (0.43in)
- Magnetic Gap Depth: 6 mm (0.24in)
- Cone Material: Water Resistant Treated Paper + water Proof Front SIde Treatment
- Surround Material: Polycotton
- Chassis Material: Aluminium
- Magnet Material: Neodymium
- Magnet Dims: 50 x 9 + 48 x 5 mm
- Driver Displacement Volume: 0.423 l (0.015ft3)
- Recommended Enclosure: 7 l (0.25ft3)
- Recommended Tuning: 107 Hz
Shipping Information
- Net weight: 0.9 kg (2.03lb)
- Multipack size (WxDxH): 374 x 374 x 191 mm (14.7 x 13.6 x 7.5in)
- Multipack weight: 11 kg (24.3lb)
