Technical specifications

• Impedance: 8 ohm
• Minimum Impedance: 6.4 ohm
• Power: 90 W
• Sensitivity: 90.5 dB
• Frequency Range: 90 - 10000 Hz
• Voice Coil Diameter: 30.5 mm
• Magnetic Gap Depth: 4 mm

Thiele and small parameters

• Resonance (Fs) - 120 Hz
• DC Resistance (Re) - 5.7 Ohm
• Diaphragm Area (Sd) - 113 cm²
• Moving Mass - System (Mms) - 7.11 g
• Force Factor (BL) - 6.32 Tm
• Maximum Linear Excursion (Xmax) - 4.33 mm
• Voice Coil Inductance (Le) - 0.258 mH
• Mechanical Q (Qms) - 1.88
• Electrical Q (Qes) - 0.736
• Total Q (Qts) - 0.53
• Compliance (Cms) - 0.27 mm/N
• Compliance Equivalent Volume (Vas) - 4.85 L

Shipping Information

• Net Weight: 0.98 kg
