4 Pack of RCF ND350 8 Ohm

The ND350 is a high frequency performance 1.75-inch diaphragm compression driver with a 1-inch exit throat. The diaphragm is precision formed from polyester.
Voice coil assembly is designed using high temperature kapton former and rectangular profile copper clad aluminium wire assembled using advanced specially formulated adhesives.


Applications:

Very compact systems
2-way and multiple way systems
Compact line arrays
Flexible and easy to crossover
Very good linearity in combination with RCF HF94, HF64, HF101 and H100 horns

Main Features:

  • 1.75-inch Diaphragm, 1-inch Exit Throat Compression Driver
  • 100W continuous program power handling
  • Frequency range: 1200Hz - 20kHz
  • 2-slot optimized geometry phase plug
  • Polyester diaphragm
  • Vented suspension system
  • Compact neodymium magnet assembly

General Specifications
Exit Throat Diameter: 25.4 / 1.0 mm/inch
Rated Impedance: 8 Ω
Power handling capacity continuous program1: 100 W AES
Power handling capacity AES2: 50 W AES
Sensitivity: 109 dB
Frequency Range: 1200 Hz ÷ 20000 Hz
Diaphragm Material: Polyester
Suspension Material: Polyester
Suspension Design: Flat
Minimum Impedance: (at 4.5kHz) 6.5 Ω
Voice Coil Diameter: 44.4 / 1.75 mm/inch
Voice Coil Material: Edgewound aluminium
Voice Coil Former Design: Straight kapton
Number of layers: 1 - outside
BL Factor: 7.5 T · m
Flux Density: 1.8 T
Phase Plug Design: 2 slots
Phase Plug Material: Composite
Magnetics: Nedymium
Mounting information
Overall diameter: 85 / 3.3 mm/inch
Overall height: 43 / 1.8 mm/inch
Mounting 4 × 5 mm holes at 90°: 76.2 / 3.0 mm/inch
Net weight: 0.8 / 1.8 kg/lbs
Shipping information
Package height: 8.5 / 3.3 mm/inch
Package width: 10 / 3.9 mm/inch
Package depth: 10 / 3.9 mm/inch
Shipping weight: 1 / 2.2 kg/lbs
