Lavoce LBASS15-15 15" Speaker Driver 100W 8 Ohm

Technical specifications

• Nominal Diameter: 380 mm (15in)
• Impedance: 8 Ohm
• Minimum Impedance: 5.9 Ohm
• AES Power: 100 W
• Program Power: 200 W
• Sensitivity: 97 dB
• Frequency Range: 35 - 4000 Hz
• Voice Coil Material: Copper
• Voice Coil Former: Glass fiber
• Voice Coil Depth: 13.3 mm ( 0.52in)
• Magnetic Gap Depth: 8 mm (0.31in)
• Cone Material: Water Proof Treated Paper
• Surround Material: Polycotton
• Chassis Material: Steel
• Magnet Material: Ferrite
• Magnet Dims: 110 x 45 x 17 mm
• Driver Displacement Volume: 3.3 l (0.12ft³)

Thiele and Small parameters:  Need some help? Read our quick guide to TS Params.

• DC Resistance (Re) - 5.5 Ohm
• Resonance (Fs) - 37 Hz
• Moving Mass - System (Mms) - 66 g
• Compliance (Cms) - 0.27 mm/N
• Force Factor (BL) - 9.9 Tm
• Mechanical Q (Qms) - 4.7
• Electrical Q (Qes) - 0.88
• Total Q (Qts) - 0.74
• Compliance Equivalent Volume (Vas) - 284 L
• Voice Coil Inductance (Le) - 0.90 mH
• Diaphragm Area (Sd) - 855 cm²
• Reference Efficiency (Eta Zero) - 1.6% %
• Maximum Linear Excursion (Xmax) - 4.7 mm
• Maximum Mechanical Excursion (Xmech) - 8.7 mm

Shipping Information

• Net weight: 4.1 kg (9.1lb)
• Multipack size (WxDxH): 438 x 438 x 204 mm (17.2 x 17.2 x 8in)
• Multipack weight: 6.2 kg (13.6lb)
